R5 Triple Pump
R5 Triple Pump
R5 Triple Pump
R5 Triple Pump
R5 Triple Pump
R5 Triple Pump

R5 Triple Pump

  • Pump type Heavy duty, cast iron, external meshing gear
  • Fluid viscosity20~100m㎡/s
  • speed 600-3000rpm
  • Import pressure-0.2-2bar
  • Fluid temperature-15℃~+80℃
  • ISO ISO 4406 C1.16/13
  • price $50~$650
Product
Parameter
Application
CONTACT US

Other Products

Company Profile

Ruichen Hydraulic Machinery Manufacturing Co., Ltd., established in 2000, is a global provider of high-quality hydraulic solutions. Located in Hebei Province, China, our 55,000 m² factory employs over 300 staff, including 15 engineers and 5 senior engineers. We specialize in cast iron gear pumps, gear motors, and hydraulic control valves, widely used in construction machinery, agricultural equipment, mining, and industrial applications.

Quality Certificate

Message

*
*

Pump displacementcm*/rev0510162025 30 35 40
continuous pressurebar250250250250250210180180
intermittent pressurebar280280280280280250210210
Minimum speed(maximum outlet pressure)rpm600600600600600600600600
Maximum speed(inlet and maximum outlet pressure)rpm3000 3000 3000 3000 3000 3000 30003000
Size “L”mm23232935.5424854.561
