JCB Hydraulic Gear Pump
A hydraulic gear pump is a type of positive displacement pump that uses meshing gears to transfer fluid by displacement. It is commonly used in hydraulic systems to generate flow and pressure.
-
- Rotation Counter Clockwise (looking from shaft end)
- Mounting FlangeSAE B 2 hole mounting flange
- ShaftSpline shaft
- Weight19KG
View details
-
- Rotation Counter Clockwise (looking from shaft end)
- Mounting FlangeSAE B 4 hole mounting flange
- ShaftSpline shaft
- Weight26KG
View details
-
- Rotation Counter Clockwise (looking from shaft end)
- Mounting FlangeSAE B 2 hole mounting flange
- ShaftSpline shaft
- Weight24KG
View details
-
- RotationClockwise (looking from shaft end)
- Shaft1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
- Mounting FlangeSAE B 2 hole
- Front Pump Displacement37 cc/rev (37L/Min per 1000 rpm)
View details
-
- RotationCounter-Clockwise (looking from shaft end)
- Shaft1.125"” Diameter parallel keyed shaft (28.8mm)
- Mounting FlangeSAE B 2 hole
- Front Pump Displacement33 cc/rev (33L/Min per 1000 rpm)
View details
-
- RotationClockwise (looking from shaft end)
- Shaft1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
- Mounting FlangeSAE B 2 hole
- Front Pump Displacement37 cc/rev (37L/Min per 1000 rpm)
View details
-
- RotationClockwise (looking from shaft end)
- Shaft1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
- Mounting FlangeSAE B 2 hole mounting flange
- Front Pump Displacement 36 cc/rev (36L/Min per 1000 rpm)
View details
-
- RotationClockwise (looking from shaft end)
- Shaft1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
- Mounting FlangeSAE B 2 hole mounting flange
- Front Pump Displacement 36 cc/rev (36L/Min per 1000 rpm)
View details
-
- Shafttapered shaft
- Displacement16cc/rev
- Weight7KG
- Ports7/8" UNF PORTS
View details
