JCB 20/925592Parker Hannifin 333/C5234 JCB 3CX Twin Hydraulic Pump 29 + 23 CC/REV

Parker Hannifin 333/C5234 JCB 3CX Twin Hydraulic Pump 29 + 23 CC/REV

Parker 20/925592 JCB 3CX Hydraulic Pump 36+16 CC/REV

30/10/2025Hydraulic Gear Pump JCB Hydraulic Gear Pump PRODUCTS 0

RotationCounter-Clockwise (looking from shaft end)
Shaft1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
Mounting FlangeSAE B 4 hole mounting flange
Front Pump Displacement36 cc/rev (33L/Min per 1000 rpm)
Rear pump displacement16 cc/rev (16L/Min per 1000 rpm)
Weight18KG
InletCombined 2” SAE flange inlet
ValveComes complete with LS priority valve
Maximum working pressure on front pump250bar
Maximum working pressure on rear pump275 bar
Max. Input shaft torque325Nm
price $190~$540

MESSAGE

Parameter

Product

Application

Replace Part Number:
20/925592, 20-925592, 20925592, 7029520007

Applications:
Fit For JCB Telehandler:
.526-56, .531-70, .531-70 SWAY, .533-105, .535-95, .535-95 SWAY, .536-70, .541-70, .541-70 SWAY, 526-56, 531-70, 531-70 SWAY, 533-105, 535-95, 535-95 SWAY, 536-70, 541-70, 541-70 SWAY

Machine Fitment

NEUTRAL CIRCUIT,LCS FIXED 2 STAGE PUMP WITH TRAILER BRAKES,AUSTRALIA & NZ 531-70 Tier 3 9812/7300
NEUTRAL CIRCUIT,LCS FIXED 2 STAGE PUMP WITH TRAILER BRAKES,AUSTRALIA & NZ 536-70 9812/7075
NEUTRAL CIRCUIT,LCS FIXED 2 STAGE PUMP WITH TRAILER BRAKES,AUSTRALIA & NZ 541-70 Tier 3 9812/7300
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 533-105 Tier 2 9812/7000
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 SWAY Tier 2 9812/7000
PUMP,(TWO STAGE) MAINH HYDRAULICS 80 L/MIN 536-70 9812/7075
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 533-105 Tier 3 9812/7085
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 Tier 3 9812/7300
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 TIER 2 9812/7060
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 Tier 3 9812/7085
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 Tier 2 9812/7000
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 535-95 MILITARY 9812/7280
PUMP,(TWO STAGE) MAINH HYDRAULICS 80 L/MIN .536-70 9812/7075
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 TIER 2 9812/7060
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 541-70 SWAY TIER 2 9812/7060
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 Tier 3 9812/7300
PUMP/MOTOR & PUMP DRIVE 526-56 9812/7350
PUMP,(TWO STAGE) MAIN HYDRAULICS 80 L/MIN 531-70 SWAY TIER 2 9812/7060
PUMP,(TWO STAGE) MAIN HYDRAULICS FITTINGS & MOUNTINGS 526-56 9812/7350
PUMP/MOTOR INSTALLATION ASSEMBLIES 2 STAGE, 80L/MIN 533-105 9822/0575
PUMP/MOTOR INSTALLATION ASSEMBLIES 80 L/Min 2 STG 14/06/2015 526-56 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES 2 STAGE, 80L/MIN 535-95 9822/0575
PUMP/MOTOR INSTALLATION ASSEMBLIES 2 STAGE 531-70WM 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES 2 STAGE 541-70WM ALL 541-70 MODELS 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES 2 STAGE 536-70AG+ 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES PUMP 2 STAGE 10/04/2016 536-70AG+ 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES PUMP 2 STAGE 526-56 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES PUMP 2 STAGE 10/04/2016 541-70WM ALL 541-70 MODELS 9822/0090
PUMP/MOTOR INSTALLATION ASSEMBLIES PUMP 2 STAGE 10/04/2016 531-70WM 9822/0090
